Specifications
Application – Gold Prospecting (Waterproof coil to 1m/3ft)
Frequency/Transmission – Zero Voltage Transmission (ZVT)
Coil (standard) – 14″ x 13″ Super‑D Configuration with skidplate (waterproof to 1 m/3 ft)
Audio Output – 6.3 mm (¼”) non waterproof socket, Wi‑Stream wireless signal transmission
Headphones Supplied – KOSS UR 30 100 ohm with 6.3 mm plug (¼-inch) (non waterproof)
Visual Display – Full color LCD (320 x 240 pixels)
Backlight – Yes
USB Connectivity – USB interface for XChange 2 PC software
Memory – Yes
Detect Modes – Gold Mode (High Yield, General, Extra Deep) Ground Type (Normal, Difficult, Severe)
Discrimination – All Metal
Audio tone – 1-100
Ground Balance – Auto and Manual (Quick‑Trak trigger button)
Sensitivity Adjust – Level (1-20)
Tune / Noise Cancel – Auto and Manual (256 channels)
Threshold – Level (1-50) Pitch (1-100)
Target Volume Adjust – Range (1-20) Limit (1-20)
Battery – Li-Ion Rechargeable Pack (7.2V DC, 72Wh)
Low battery alert – Yes
Length – Collapsed: 1170 mm (46.1”) Laid flat, packed position: 1304 mm (51.3”) Extended: 1526 mm (60.1”) Laid flat, packed position: 1651 mm (65.0”)
Weight – 3.32 kg (7.32 lb) (Including GPZ 14 coil, skidplate and 72Wh battery)
Warranty – 3 years control box & coil
Please note that these specifications are subject to change by the manufacturer.
